QUICK 2in1 Reworkstation digital 1350W, hot air (1280W) up to 500°C, 100 levels, max. 50 L/min., 70W soldering station up to 480°C, auto-standby for hot air, calibration function, constant output temperature with 6-piece accessory set
The QUICK 709D+ Rework Station is the ideal choice for professional users who require precision and performance. With its state-of-the-art technology and robust construction, it offers a variety of features for demanding soldering and repair work.
This soldering station has a precise temperature control that allows for accurate adjustment of the soldering temperature to achieve optimal results. The wide temperature range and fast heat-up time ensure efficient work in a variety of applications.
The QU709D+ is equipped with a user-friendly control panel that allows easy control of all functions. Thanks to its ergonomic design and intuitive operation, it is suitable for both experienced professionals and beginners.
Additional features include a high-quality soldering iron with a long-lasting tip, a powerful hot air pencil for precise rework applications.
In addition, the QU709D+ offers a variety of safety features, including an automatic standby mode and overheating protection, to ensure a safe working environment.
Overall, the QU709D+ rework soldering station is the perfect solution for demanding soldering and repair work in a range of industries and applications.
Technical data:
Hot air 1280W up to 500°C
100 levels max. 50 L/min,
soldering station 70W up to 480°C
Auto-standby for hot air
calibration function
constant output temperature
heat-up time to 350°C: approx. 50s
display: LCD
power: 1350W (of which 70W soldering iron)
operating voltage: 230 V / 50 Hz
Temperature range: hot air 100-500 °C / soldering iron 100 – 480 °C
Temperature stability: hot air ± 5 °C / soldering iron ± 2 °C
Ambient temperature: 0 – 40 °C
Hot air setting range: maximum 50 L / min.
Soldering tip to ground potential: <2 mV
Soldering tip to ground resistance: <2Ω
Dimensions W-H-D: 210x131x210 mm
Weight: 3.3 kg
Conformity: RoHS, CE
Scope of delivery:
– QUICK 2 in 1 rework station digital
– Soldering iron 901RAA
hot air pencil TR3-P-ZZ-01
– holder with brass cleaning wool
– 3x hot air nozzles A2025 (3mm), A2064 (6.4mm) and A2084 (8.4mm)
– straight permanent soldering tip, needle-point, Ø 0.2 mm
– Accessory set consisting of: ESD work mat, ESD precision tweezers SET, mini side cutter, permanent soldering tip set, flux gel 20g and soldering wire clear Sn100Ni+ 50g
